3000-MA Series Rear Counterweight Duplex-Specific Elevator
The 3000-MA Series Rear Counterweight Duplex-Specific Elevator is sophisticated and space-efficient vertical transportation solution exclusively designed for duplex houses and two-story residential applications. Leveraging a specialized compact drive system, it delivers exceptional stability and smooth operation, perfectly tailored to the unique height constraints and layout requirements of duplex buildings.
Product Parameter (specification)
| Item | Specification |
| Drive System | Globally Leading Traction Steel Belt Drive |
| Design Philosophy | Minimalist Design with Three "Nos" |
| Design Detail 1 | No visible connecting bolts |
| Design Detail 2 | No visible shaft cables |
| Design Detail 3 | No visible running components |
| Minimum Shaft Size | 1100mm × 950mm |
| Minimum Ceiling Height | 2400mm |
| Minimum Pit Depth | 100mm |
| Floor Coverage | 2 ~ 6 floors |
3000-MA Rear Counterweight
| Item | Formula / Specification |
| Minimum shaft width (HW min) | HW min = 950mm |
| Maximum shaft width (HW max) | HW max = 1420mm |
| Minimum shaft depth (HD min) | HD min = 1100mm |
| Cabin net width (CW) | CW = HW − 130mm |
| Cabin net depth (CD) | CD = HD − 450mm |
| Door net width (DW) | DW = HW − 280mm |
| Maximum shaft depth (HD min) | HD max = 1330mm |
Hoistway drawing
Product Configuration
Plantform Options
Aluminum alloy structure platform, high-end rock plate or leather soft-pack avant-garde customization
HWJ-771
Soft pack-9
HWJ-761
Fendi grey
Cabin Options
Feature
Globally Leading Traction Steel Belt Drive
Adopts a state-of-the-art traction steel belt drive system, delivering smooth, quiet, and stable operation with enhanced safety and extended service life.
-Minimalist Design with Three "Nos"
- No visible connecting bolts
- No visible shaft cables
- No visible running components
Creates a clean, sleek interior appearance while maintaining structural integrity and safety.
Space-Efficient L-Shaped Platform: Optimized for wheelchair accessibility and easy entry/exit, ideal for home use.
Flexible Installation: Supports shallow pit/no-pit and low overhead requirements, suitable for both new construction and retrofitting.
Safety & Reliability: Equipped with comprehensive safety features including emergency leveling, overload protection, and safety interlocks.
Customization: Offers a wide range of finishes, materials, and door configurations to match home decor.
Application
Perfect for villas, private homes, duplex apartments, and small residential buildings, providing a luxurious and convenient vertical transportation solution.
Delivery, Shipping & Service
Door-to-Door Delivery
We deliver your HomeWay 1000 Series home elevator safely to your location, with full tracking and on-time guarantee.
Professional Installation
Certified technicians handle on-site setup, ensuring compliance with local safety standards and smooth operation of your residential elevator.
24/7 Support & Maintenance
Emergency response, regular check-ups, and genuine parts supply-we've got your home elevator covered for long-term reliability.
FAQ
Q: What's the maximum load capacity of Homeway home elevators?
A: Our home elevators typically support 3–5 persons, with a load capacity ranging from 250 kg to 400 kg according to different models.
Q: Does Homeway provide on-site measurement service?
A: Yes, our professional engineers can provide on-site measuring and planning to ensure the elevator fits your building structure perfectly.
Q: What's the average power consumption of a home elevator?
A: Homeway home elevators are energy-saving. The daily power consumption is similar to a common household refrigerator, very economical.
Q: Can the elevator run quietly without disturbing family life?
A: Yes. We use silent traction systems and shock absorption design, ensuring low noise during operation.
Q: Are your home elevators suitable for elderly or disabled users?
A: Absolutely. Our elevators feature barrier-free design, stable running, easy operation, and safe functions for the elderly and people with limited mobility.
Q: Does the elevator need a separate shaft or pit?
A: For most models, a small pit is recommended, but we also offer pit-less or shallow-pit solutions for homes that cannot be renovated.
Q: Can I choose different door opening types?
A: Yes, we support center opening doors, side opening doors, and telescopic doors to match different space layouts.
Q: How long is the service life of Homeway home elevators?
A: With proper maintenance, the service life can reach 15–20 years, and key components can be replaced to extend usage time.
Q: Will installation cause heavy damage to the house?
A: No. Our installation is lightweight and will not damage the main building structure, with short construction period.
Q: Can we get technical support if we have our own installation team?
A: Yes. We provide detailed installation manuals, video tutorials, and online technical guidance for your installation team.
